Custom BRS 12V 50A Bimetal Switch Thermostat / Motor Temperature Controller

Product Categories

Jiangsu ChangSheng Electric Appliance Co., Ltd

Contact Now

Name: Custom BRS 12V 50A Bimetal Switch Thermostat Motor Temperature Controller
Brand: DESHENG
Price: 1 USD

Place of Origin : China

Brand Name : DESHENG

Certification : UL CQC

Model Number : BRS series

MOQ : 500pcs

Packaging Details : 2000pcs per package

Delivery Time : 10-12 days on order date

Payment Terms : T/T L/C D/P

Supply Ability : 200,000pcs/month

Contact capacity : 125Vac/16A, 250Vac/8A 600Vac/4A 24Vdc/20A

Product Name : Bimetal Circuit Breaker

Cycles life : 6,000-10,000cycles

Seal : High-seal and low-seal gaske

Certifications : UL,VDE,CE CQC

Temperature Tolerance : ±5°C

Contact Now

Custom BRS 12V 50A Bimetal Switch Thermostat / Motor Temperature Controller

Description:

Snap-action bimetal disc

Fault conditions up to 100 amps

Compact and eady to install

Individually temperature calibrated and checked.

The BRS design provides protection against various fault conditions, such as: locked rotor, running overload, low voltage, run both windings.

Applications:

Split-phase motors

Specifications:

Contact capacity	12Vdc/50A 12Vdc/60A 12Vdc/80A 12Vdc/100A
Cut-out time	2-50 seconds (at 25℃) customer-designed is available.

Competitive Advantage:

1.High current motor protector

2. Customer can design the cut out time.

3. Individually cutoff time checked

4. Snap–action disc, normally on.

Custom BRS 12V 50A Bimetal Switch Thermostat / Motor Temperature Controller
